78 Chapter 5 Configuring VoIP trunks
P0993474 03
Ensure that no other line pools use this access code. Also ensure that this access code is not
used for any other type of code, such as destination codes or DISA DNs.
Configuring telephones to access the VoIP lines
For each telephone that will be allowed to use the VoIP lines, you must add that line pool to the
DN record:
1 In Unified Manager, open Services, Telephony Services, System DNs, Active Set DNs, DN
XXX, Line Access. DN XXX is any DN that you want to allow to use VoIP trunking.
2 Click Line Pool Access.
3 Click Add.
The Add Line Pool Access dialog appears.
4 Type the letter of the VoIP line pool.
5 Click Save.
6 Repeat this procedure for every telephone you want to allow to use VoIP trunks.
Configuring a remote gateway
This section explains how to configure the Business Communications Manager to communicate
with other Business Communications Managers and/or other VoIP gateways such as Meridian
ITG. The remote gateway list must contain an entry for every remote system to which you want to
make VoIP calls.
To add an entry to the remote gateway list:
1 In Unified Manager, open Services, IP Telephony, H.323 Trunks, and click on Remote
Gateway.
The remote gateway tab appears. The Remote Gateway screen shows all gateway records that
have been added to the system.
2 On the top menu, click Configuration, and select Add entry.
If you are modifying an existing entry, select the entry, then, under Configuration, select
Modify entry.
The Remote Gateway window appears as shown in the next figure.
Note: Gatekeeper
If your system is controlled by a gatekeeper, you do not need to establish these gateways.
Refer to “Using a gatekeeper” on page 103.
